Almon Johnson Spooling Unit

This SR001 spooling unit was specifically designed and built to handle Manuli flexible riser. The spooling machine can also handle jumper hoses, umbilical, and long length fibre ropes for deep water moorings. It has a Hagglund motor, and is electro hydraulically driven. The unit is road transportable and comes with level winder, steel foundation and 65te lift beam. Fully loaded it can take 1200m of 6” i.d hose.

Dimensions: length 9.75m x Width 3.75m x height 4.40m

weight: 24te.

Line Pull: 15te

Core Radius: 1.25m

Load Capacity: 120te 1200m 6″ id hose

This unit is also road transportable.
